ZD electric car

• Min. Order:1
• 2020 city eec electric small mini car
• Specification Description:ZD

items	Model			D2S EEC	D3 NO EEC
basic configuration	dimensions(L*W*H)			2811mm*1499mm*1555mm	2975mm*1585mm*1590mm
	Wheelbase			1765mm	1865mm
	max speed km/h			85	105	105
	maximum gradability			≥20%	≥20%	≥20%
	range in NEDC km			155	165	305
	range in average speed 60km/h			180	210	380
electric components configuration	Motor	PMSM		●	●	●
		front wheel driven		●	●	●
		power: 9KW/18KW		●
		power: 15KW/30KW		○	●	●
	power pack	Li(NiCoMn)O2		17KWH	17KWH	35KWH
	motor controller			●	●	●
	power regeneration			●	●	●
	on board charger 7-phasis as EU standard			●	●	●
	DC-DC converter			●	●	●
	BMS/VMS/CAN			●	●	●
	charging time			6-8h	6h	5.5h
	vehicle Diagnose monitoring system			●	●	●
	manual inverter air conditioner	cooling /heating		●	●	●
chassis and steering	electrical acceleration pedel			●	●	●
	steering column: angle adjustable			●	●	●
	steeing wheel	leather		●	●	●
	steering	EPS		●	●	●
		Mechanical steering lock anti-theft		●	●	●
		ESCL		●	●	●
	suspension	front	McPherson suspension	●	●	●
		back	trailing type independent	●	●	●
	brake	front and back:disc		●	●	●
		foot parking brake		●	●	●
	wheel rim	aluminium alloy		●	●	●
	tyre	front: 145/60 R13		●	─	─
		front: 165/50 R15		─	●	●
		back: 155/50 R14		●	─	─
		back: 165/50 R15		─	●	●
	ABS+EBD			●	●	●
	switch control	Rotary switch		●	●	●
	visual reverse system			●	●	●
	BMS/VMS/CAN			●	●	●
	central control lock			●	●	●
	digital remote control key			●	●	●
	keyless start system (one press start)			●	●	●
	overspeed alarm/door open alarm			●	●	●
multi-media configuration	car-mounted system	system	android 9 inch	●	●	●
		bluetooth/radio/USB/SD		●	●	●
	GPRS terminal/GPS			○	○	○
	Navigation system			○	○	○
safety measurement	safety belt			●	●	●
	air-bag for driver			●	●	●
windows	wiper			●	●	●
	window lifting system: electrical			●	●	●
	rear defroster			●	●	●
rearview mirror	exterior and interior rearview mirrow	electrical adjustable and manual folded		●	●	●
		mechanical anti-glare		●	●	●
seats	seats	PVC		●	●	●
interior configuration	instrument cluster	LED digital screen		●	●	●
	safety handle	co-driver side		─	●	●
	PM 2.5 filter			─	●	●
light configuration	front and rear group lights			●	●	●
	front fog light			●	─	─
	Auto turing light Assist			●	●	●
remark：●:standard,○:optional,─:none / The configuration is subject to change, pls refer to real vehicle.

FAQ
Question 1: How to place an order?
A: The procedure is like this:
1). Contact customer service to determine the freight and product model, configuration, quantity and other detailed information (you can also arrange freight forwarding by yourself);
2). We provide you with a proforma invoice according to your final decision, which contains all product details;
3). You need to arrange 30% of the payment to our bank account, and then we will prepare the product to start production (the cycle is generally about 10 days, which can be shipped specifically for your order configuration quantity);
4). After the product is completed, the remaining payment is paid, and we arrange forwarder delivery (or we provide relevant information to arrange forwarder transportation by ourselves).
5). After completing this process, the customer service will track the product location and notify you when it is about to arrive and when it arrives, so that you can quickly prepare for customs clearance and other related issues.
6). After getting the items, there will be a dedicated after-sales team waiting for your follow-up feedback.

Q2. What does your FOB reference price include?
A: FOB price only includes cost. If you do not have your own freight forwarder, please provide us with a port near you
Countries/regions, we will quote CIF prices including shipping costs.
